Dynemech Anti-Vibration Technology: Advanced Isolation
Solutions for Precision, Productivity, and Performance”
The business we operate, Dynemech Anti-Vibration Technology.,
has responsibility for the development, engineering, and construction of the
most comprehensive selection of Dynemech Anti-Vibration Pads, silent blocks, shock and
noise control products. In addition, we are highly skilled in the production of
Anti-Vibration regulating pads, equipment mounts, Spring Mounts, and a variety
of Anti-Vibration Pads. One of the most well-known manufacturers of Anti-Vibration
cushions is Dynemech Systems Pvt. Ltd.
The Anti-Vibration Pad
offered by Dynemech Systems Pvt. Ltd. is
the ideal option given your situation.
Manufactured from a combination of high-quality rubber
polymers and cork, the ideal mixture finally results in the formation of a
product that possesses exceptional resistance to water and oil, as well as
excellent aging and compression set. Dynemech Anti-Vibration Pads manufactured
by Dynemech Systems Pvt. Ltd. have a wide range of applications, including
but not limited to the following: refrigeration plants, compressors, conveyors,
air conditioning plants, diesel generators, business machines, fans, motors,
power and impact presses, pumps, CNC machines, and many more. The silent block
series that we offer is ideal for controlling the vibrations of machines. When
it comes to managing active and passive vibrations from a variety of industrial
devices, our products that are based on rubber are ideal.
A crochet knitting machine that is equipped with Dynemech Systems Pvt. Ltd. spring has been installed.
Dynemech Systems Pvt. Ltd. Spring Isolator gives desired natural frequency to
obtain phase difference in the frequencies for a rotating machine and impact
generating machine. Viscous damping is an important feature of an isolation system.
In most cases viscous damping is required to limit excessive movement which
could occur as a machine operates at a speed near to, or coinciding with the
resonant frequencies of the system.
Generally this problem arises during slow run up and run
down of rotating machines and during impact at each stroke in presses and
hammers.
The microscope is mounted atop a Dynemech Anti-Vibration Table, which is part
of the DIT-AM series.
Dynemech Anti Vibration Table DIT AM-HC has natural frequency in the range of
1-1.5 Hz along with self-levelling feature. Available self-levelling accuracy
is +-0.10 mm with minimum setting time, depending upon the application requirement.
Dynemech Membrance AirSprings are used which damps most of the incoming vibrations above 4 Hz. Level
difference on top of the honey comb table top surface due to any load change
and the equipment if compensated within milliseconds. Used in optical
industries, for mounting optical assemblies.
A Housing Closing Machine that is mounted on a Dynemech Spring Isolator
Housing closure machines exert a significant amount of force in a manner that
is repeated and cyclical.
This typically results in powerful vibrations that are
transmitted to the floor and may cause misalignment during the process of
product assembly. These machines, when installed on Dynemech Spring Isolators,are able to realize better vibration decoupling technology.
This technology separates the machine operating forces from
the structure and the ground, thereby reducing the amount of impact transfer
while maintaining the structural health of the plant and the foundation. The
isolators are constantly adjusted to the dynamic nature of the plant, which
guarantees the highest possible energy absorption, enhanced precision during
closure operations, and a significant reduction in the amount of operator wear
and maintenance.
Installation of a Vertical Machining Center (VMC) on a Dynemech Wedge Mount
derived from the Series DBO
Dynemech Wedge Mounts, Series are designed for industrial machine tools that
require Precision Levelling assembled with respective Dynemech InsulationPlates.
Dynemech Wedge Mounts, Series have a height of 100/150mm at mean position to
help proper cleaning and repairing under the machines, with specs similar to
series.
Coordinate Measuring Machines (CMMs) that are mounted on Dynemech Membrane AirSprings and have an Inertia Mass
Dynemech Systems Pvt. Ltd. DMAS system consists of three master pneumatic
isolators for 3-point Precision Levelling. Each pneumatic damping isolator
consists of a self-levelling plunger mechanism, which is the load sensing, and
height-controlling element. The system is supplied with pressure regulator,
distributor, non-return valve and other pneumatic accessories necessary for
complete systems installation. Clean dry air is required to be supplied to the
system.
The installation of CMMs on Dynemech Membrane Air Springswith Inertia Mass results in the creation of an extremely stable floating
platform that has natural frequencies ranging from 0.5 to 2 Hz. While the Air Springs
Isolate external vibrations and give sub-micron level accuracy, the inertia
mass serves as a stable platform for the device.
The standards of the
metrology lab are addressed by this setup, which also achieves an improvement
in the repeatability of measurements in actual operational conditions.
In the series VHS-LA, the horizontal boring and milling machine is mounted on
the Dynemech Systems Pvt. Ltd. fixators.
Horizontal boring and milling machines are among the most vibration-prone and
heaviest pieces of industrial machinery. This is due to the fact that they have
enormous worktables, high-speed spindles, and powerful cutting forces.
The Dynemech Systems Pvt. Ltd. Fixators Series VHS-LA mounts
are Vibration Isolation and Levelling Mounts designed for situations that need
a high level of intensity. A sturdy and vibration-free platform is provided by
the fixators, which are constructed with a reinforced steel frame and dampening
elastomers integrated into their design features.
In addition to
protecting the machine and the shop floor, the fixators reduce the amount of
micromovements that occur on the machine, ensure that the machine will remain
stable over the long term, and improve alignment as well as the accuracy of
boring and milling.
Series DIT-AM Equator Gauging System on Anti-Vibration Table is the seventh
item on the list.
In order to ensure its repeatability and performance, the Equator Gauging
System, which is used for comparative gauging in production applications, requires
a surface that is both vibration-free and controlled. Because it is mounted on
the Dynemech Anti-Vibration Table Series DIT-AM, the gauging system is shielded
from vibrations that are transmitted through the floor, changes in temperature,
and operating disturbances that are caused by machines that are located nearby.
The use of anti-resonance materials, in addition to the
vibration-damping construction of the table, serves to shield measurement
cycles from disruptions that are caused by the surrounding environment.
For the purpose of satisfying the precision needs of
industries like as aerospace and automotive manufacture, this arrangement
offers quality control feedback that is both quick and exact in scenarios
involving volume manufacturing.
The Dynemech Air Damping System with
Viscous Damping – Series DRAS-VD has been outfitted with a high-speed press.
Dynemech Rubber Air Springs provide highly effective insulation of machines
against low frequency vibration/ impact. The element offers a vertical natural
frequencies between 2.5 to 6.0 Hz*. The component has vertical to horizontal
stiffness ratio of approximately one. Suited for both active and passive
vibration control.
Active isolation of high speed power presses, textile
machines, vibration test rings, engine test beds, blowers etc. and passive
insulation of measuring & testing machines/equipments, high precision
grinding/polishing.
