Lathe machinery is one of the most important machine tool in manufacturing industries.  Interaction between motors, pulleys, sheaves, chuck and gears cause vibrations in all CNC lathes and Lathe machinery. Besides, self-excited chatter is a basic performance limitation in the machining of metals in all  heavy duty lathe machines, requiring Dynemech Leveling Mounts to optimize performance.

WEDGE ACTION VIBRATION DAMPERS

 Moreover, Lathe machine tools are liable to deterioration in their performance level with respect to time due to various causes such as wear and tear, ageing, unbalance, looseness of parts etc. and produce a corresponding increase of the vibration level. So, better vibration damping and vibration isolation with leveler anti vibration jacks and vibro mounts becomes imperative. Add to this the high vibration frequencies due to belt tension fluctuations, gear tooth frequencies at the mating gears, defects in bearing and unwanted vibrations due to unbalance rotors. All the vibration related problems are addressed when Lathes are installed on Dynemech Lathe leveling jacks and vibration damping leveling mounts.

No Vibration Transmission-Lathe Machinery Mounts

Machine tool vibration in CNC lathes and heavy duty lathes, if uncontrolled, can adversely affect the surface finish, dimensional accuracy and tool life. About 70% of the failures in the machine tool could be due to increased disturbing vibration level of the machine leading to production failures and maintenance issues. Dynemech Lathe leveller jacks and leveler feet for lathe offers economical solutions to such critical and costly production issues.

Heavy Duty Lathe Machine Fixators and Anti Vibration Mounts

Precision Leveling Jacks for accurate alignment of Long Bedded Lathes

Lathes having heavier stands are better at dampening the vibrations. But, even strong, cast iron bases, because of their inherent metallic structures, are not always adequate by themselves at damping vibrations generated during the machining operations. For these Leveling plate for lathes –elastomeric leveling jacks , spring viscous leveling mounts or pneumatic vibration dampers or leveling jacks are required. Reducing or damping vibration in a lathe is important for several reasons. It is imperative for more precise machining by allowing greater dimensional control, leading to improved surface finishes on the machined part and allowing faster machining speeds and heavier or deeper cuts.

PRECISION LEVELERS AND FIXATOR MACHINERY JACKS

All these attributes can be obtained by precise leveling and accurate alignment of lathes on Dynemech Leveling Jacks and Machinery Mounts. Reduced vibration also increases reliability and tool/machine life and can reduce noise from the machining operation.

Vibration damping can be defined as the capacity of a mechanical system to reduce the intensity of a vibratory process. Dynemech vibration isolation solutions and leveling jacks lead to reduction of intensity of undesirable resonances; acceleration decay(settling) of transient vibration excited by abrupt changes in motion parameters of mechanical components; prevention or alleviation of self-excited vibrations; prevention of impacts between vibrating parts when their amplitudes are reduced by damping; potential for increase in efficiency due to reduced peak vibratory velocities of components having frictional or micro impacting interactions; reduction of noise generation and of harmful vibrations transmitted to human operators and surrounding building structures.

Vibration Control in Lathes installed on Dynemech Anti Vibration Mounts

The primary effect of increased damping in a structure through leveleing jacks and leveling feet is a reduction of vibration amplitudes at resonances, with corresponding decreases in stresses, displacements, fatigue and sound radiation.

Vibration and Levelling of Lathes mounted on DYNEMECH's Vibro Dampers

DYNEMECH range of anti vibration machinery mounting systems including wedge action leveling jack and machinery leveling shock mounts isolate all kinds of vibration generated in the machinery and also buffer the machine against vibrations travelling from the surrounding environments to the machine itself.

Elastomeric AV Mounts for Vibration and Noise control

Dynemech Wedge Jacks and machinery leveling shock mounts, Series DT are designed for machines which are top heavy or have eccentric motion or machines which must be anchored to the ground. They can be used without insulation plates or lathe rubber pads for precision levelling and alignment in all spatial axes along with centric anchoring. Series DTO with single center hole improve alignment accuracy, rigidity and stability in long bedded machinery both with and without machinery rubber feet.

 CNC Lathe machine installed on Antivibration Mounts for Vibration Control

Vibration and Shock Control Leveling Jacks for CNC Lathe Machinery

Dynemech Leveling Foot Mounts VHS Series is used for precision leveling and aligning machinery to very strict tolerances and makes it possible to vary adjustments at any time, even under maximum loads requiring only a small hand wrench to adjust.

Vibration Control in Heavy Duty Lathe Machines

Dynemech's Lathe Machinery Leveling Jacks  DTH Series mounts are designed for Lathe machines which require high height adjustment and critical precision levelling and alignment. They have a large leveling range with sturdy dimensional parameters.

Dynemech Lathe shock mounts TPM Series Mounts have a height of 100mm/150 at mean position to help proper cleaning and repairing under the machine as per TPM guidelines for machine installation by IMTMA. Vibration reduction is possible through assembling respective Dynemech insulation plates.

For further details contact :

Dynemech Systems Pvt. Ltd.

Ph:9810760131,9911145131

www.vibrationmountsindia.com

Just wanted to wish you all a Merry Christmas, Happy Holidays, or a Happy whatever you are celebrating at this time of year.

The Dynemech Team

End to Vibrations in Injection Moulding Machines

Endto Vibrations in Injection Moulding Machines

Vibrations in Mitsubishi 850 TonInjection Moulding Machine: Vibration Isolation with Wedge Mounts, Series DBwith Du insulation plate

The noise and vibration problems created by injection moulding machines can be moderated by the installation of vibration absorbers. The composite material insulation plates help in energy absorption and reduction of noise and vibration.

Vertical adjustment wedge mounts are ideal solutions for precise, accurate, efficient and economical machinery levelling and installations.

Besides, vibration reduction and vibration isolation other benefits availed are:

ü  Rugged heavy duty construction of the mounts with varied load carting capacities

ü  Precise levelling with easy and smooth adjustment

ü  Enhanced machine stability as machine bolted to vibration reduction mounts.

ü  Relocation of machinery possible as no grouting or bolting necessary.

ü   “Machine Walking” prevented as per OSHA requirements.

Injection Moulding Mounts

For further details contact :

Dynemech Systems Pvt. Ltd.

Ph:9810760131,9911145131

www.vibrationmountsindia.com

Machine Vibration Pads - Vibro Damper Pads for Shearing Machines

Vibro Damper Pads for Shearing Machines

Shearing, also known as die cutting is a process which cuts stock without the formation of chips or the use of burning or melting. Such impact generating machines inherently suffer from unwanted vibrations thus, necessitating the need for Dynemech Vibro Dampers.

Figure 1: Vibro Damping Mounts for all Impact Generating Machines

 Machining and Shearing operations like blanking, piercing, roll slitting, and trimming are invariably accompanied by relative vibration between work piece and tool. These vibrations can be due to inhomogeneities in the work piece material; disturbances in the work piece or tool drives; dynamic loads generated by acceleration/deceleration of massive moving components; vibration transmitted from the environment(passive vibration transmission); self-excited vibration (active vibration transmission) generated by the cutting process or by friction (machine-tool chatter). Modern Installation technique entails installation of equipments on VIBRO DAMPERS to protect from shock and vibrations which are inherent in all manufacturing environments. Dynemech Vibro Dampers are highly efficient, proven and economical vibration and shock isolators.

Figure 2: Shear supported on Vibro Damper RubberMounts for Vibration Isolation
